3. SSH 密钥认证

密码认证存在诸多不便,如:

  • 简单密码,易被破解,复杂密码记不住

  • 每次登录都需输入密码,十分不便,也容易泄露

3.1. 密钥认证

简单来说,密钥如同以前的虎符:

../_images/%E8%99%8E%E7%AC%A6.jpg

虎符成对,皇帝和统帅各执一半,调兵遣将则需虎符符合。

  • 密钥也成对,分为公钥和私钥,不过公私钥是人为规定的。皇帝和统帅的虎符互换,并没有实质影响,公私钥亦是如此,人为定义是为了方便管理。

  • 密钥安装就是皇帝给予统帅一半虎符。

  • 密钥认证就是检验虎符是否符合的过程,只有密钥成对才能通过认证。

虽说公私密钥没有差别,但实际使用还是应当保存私钥,分发公钥,一旦混淆,可能江山不保。

备注

密钥认证原理涉及密码学,可以参阅《图解密码学》

3.2. 密钥生成

ssh-keygen 命令负责管理密钥相关事物,默认情况下,会以交互形式生成密钥。

 1ubuntu@VM-32-12-ubuntu:~$ ssh-keygen
 2Generating public/private rsa key pair.
 3Enter file in which to save the key (/home/ubuntu/.ssh/id_rsa):
 4Created directory '/home/ubuntu/.ssh'.
 5Enter passphrase (empty for no passphrase):
 6Enter same passphrase again:
 7Your identification has been saved in /home/ubuntu/.ssh/id_rsa.
 8Your public key has been saved in /home/ubuntu/.ssh/id_rsa.pub.
 9The key fingerprint is:
10SHA256:fN9Z3ujWNjPGf98YuCp1f+lO3OwhxHSH17Vv5kqrssM ubuntu@VM-32-12-ubuntu
11The key's randomart image is:
12+---[RSA 2048]----+
13|                .|
14|               .+|
15|             ..o+|
16|       .    o ..o|
17|        S .  o  =|
18|         ...oo.Xo|
19|         o .ooB=B|
20|        . E  +=&B|
21|         .o=ooO=%|
22+----[SHA256]-----+
  • 第三行提示公私密钥对存储的位置和名字,输入 Enter,使用默认位置和命名。

  • 第五第六行要求输入密钥的密码,输入 Enter,不使用密码。

密钥生成结果如下:

ls -al .ssh/
total 16
drwx------ 2 ubuntu ubuntu 4096 Dec 20 02:30 .
drwx------ 1 ubuntu ubuntu 4096 Dec 20 02:30 ..
-rw------- 1 ubuntu ubuntu 2602 Dec 20 02:30 id_rsa
-rw-r--r-- 1 ubuntu ubuntu  571 Dec 20 02:30 id_rsa.pub

3.3. 密钥事项

更改位置与命名:

通常会使用默认参数,但多个密钥时,则需更改,避免密钥被覆盖。

Enter file in which to save the key (/home/ubuntu/.ssh/id_rsa): /tmp/testkey

密码保护:

大多数人不会使用密码保护密钥,主要是嫌麻烦,其实 ssh-agent 可以减少输入密码的负担。

更改密钥密码:

ssh-keygen -p -f ~/.ssh/id_rsa

交互过程可能需要输入原密码,或直接选项提供原密码。

ssh-keygen -p -f ~/.ssh/id_rsa -P "12345678"

无交互生成密钥:

ssh-keygen 的部分帮助信息如下:

ssh-keygen [-q] [-b bits] [-C comment] [-f output_keyfile] [-m format]
                [-t dsa | ecdsa | ecdsa-sk | ed25519 | ed25519-sk | rsa]
                [-N new_passphrase] [-O option] [-w provider]

通常使用以下命令生成密钥对:

ssh-keygen -q -b 2048 -C "dummy key" -f ~/.ssh/id_rsa -t rsa -N ""
  • -b 指定密钥位数,1024 的倍数,越大越安全

  • -C 添加注释,方便后续查阅与区分

  • -f 指定目录与密钥名称

  • -t 指定密钥类型,上述类型任选其一

  • -N 指定密码,此处为空。注意,shell history 会存储该命令,从而泄露密码

密钥权限:

在数据迁移时,可能在 Linux 和 Windows 之间交互数据,这会导致密钥权限发生变更,错误的权限将导致密钥不可用,详见附录:SSH 附录: ssh 文件权限管理

@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
@         WARNING: UNPROTECTED PRIVATE KEY FILE!          @
@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@
Permissions 0666 for '/home/ubuntu/.ssh/id_rsa' are too open.
It is required that your private key files are NOT accessible by others.
This private key will be ignored.
Load key "/home/ubuntu/.ssh/id_rsa": bad permissions
dummy@10.0.0.1's password:

3.4. 密钥安装

Linux 是多用户系统,认证所需的公钥存放在每个用户的 ssh/authorized_keys 文件中。

通常可以使用以下命令安装密钥,过程中需要输入登录密码。

$ ssh-copy-id dummy@10.0.0.1
/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/home/ubuntu/.ssh/id_rsa.pub"
/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed
/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys
dummy@10.0.0.1's password:

Number of key(s) added: 1

Now try logging into the machine, with:   "ssh 'dummy@10.0.0.1'"
and check to make sure that only the key(s) you wanted were added.

-i 选项可以指定密钥。

ssh-copy-id -i "/home/ubuntu/.ssh/test" dummy@10.0.0.1

公钥是可以公开的,管理大量主机时,很可能把公钥直接放到网上,然后直接脚本安装。

注意: 以下操作在服务器上执行,而不是生成密钥的客户端,公钥需提前放在网上。

创建公钥存储文件
mkdir -m 700 -p ~/.ssh && (umask 077 && touch ~/.ssh/authorized_keys)
下载与安装公钥
export KEY=$(mktemp /tmp/key.XXXXXXXXX)
curl -fsSL -o ${KEY} <url for your public key>
cat ${KEY} >> ~/.ssh/authorized_keys

操作方式多种多样,只要满足以下两个条件即可:

3.5. 启用密钥登陆

如前所述,sshd 的配置文件为 /etc/ssh/sshd_config,需更改如下选项:

PS: # 开头的选项既是注释,也是默认配置,如 #PubkeyAuthentication yes,表示默认启用密钥认证,因此无需做任何修改。

开启密钥认证:

PubkeyAuthentication yes

关闭密码认证:

PasswordAuthentication no

重启服务:

systemctl restart sshd

3.6. ssh-agent

ssh-agent 用于管理密钥,相当于 ssh_config,但略有差异。

简单来说,我们将全部密钥导入 ssh-agent,解密后的密钥保存在内存中,使用时我们将数据传入 ssh-agent, 由 ssh-agent 进行中转,认证时 ssh-agent 用解密的密钥进行认证。

创建 ssh-agent 进程:

eval `ssh-agent`
# 或
eval $(ssh-agent)

添加密钥,默认添加 ~/.ssh/id_rsa 密钥,其它密钥需要指定,加密密钥需要输入密码解密:

ssh-add ~/.ssh/id_rsa
Enter passphrase for /home/dummy/.ssh/id_rsa:
Identity added: /home/dummy/.ssh/id_rsa (/home/dummy/.ssh/id_rsa)

查看密钥:

ssh-add -l
2048 SHA256:llqLOpAH+6NPh4y71WND3Ukxq1l6FVCYMt2aCS+snSU /home/dummy/.ssh/id_rsa (RSA)

删除密钥:

ssh-add -D                              # 删除全部密钥
ssh-add -d /home/dummy/.ssh/id_rsa      # 删除指定密钥

在添加密钥后,可以按照原有方式进行连接,甚至配置文件都不需要指定密钥:

ssh-keygen -l -f ~/.ssh/id_rsa
2048 SHA256:llqLOpAH+6NPh4y71WND3Ukxq1l6FVCYMt2aCS+snSU dummy@test (RSA)
ssh-keygen -l -f ~/.ssh/id_rsa.pub
2048 SHA256:llqLOpAH+6NPh4y71WND3Ukxq1l6FVCYMt2aCS+snSU dummy@test (RSA)

查看密钥对的指纹信息,公私密钥的指纹信息是相同的,因此可以自动匹配密钥。

大多情况,ssh config 足以管理认证,个人猜测 ssh-agent 主要用于大公司管理服务器集群。

在别的文章看到还需做以下配置,但测试时,发现无需开启,可能是实现差异。

ssh_config (全局,个人,选项任选其一配置)

ForwardAgent yes

sshd_config

AllowAgentForwarding yes
